Art. No.

Thread Size

Wire mm

A (mm)

D (mm)

H (mm)

D1 (mm)

D2 (mm)

L3 (mm)

L1 (mm)

L2 (mm)

KG/100

B.L.KG.

SS-B1007-0603

M6

3

8

6

13

3.3

6.35

39

200

270

8.5

1250

SS-B1007-0604

M6

4

8

6

13

4.3

7.5

45

210

280

9

1250

SS-B1007-0804

M8

4

10

8

16

4.3

7.5

45

240

310

16

2350

SS-B1007-0805

M8

5

10

8

16

5.3

9

52

250

320

16.5

2350

SS-B1007-1005

M10

5

12

9

20

5.3

9

52

280

360

31

3500

SS-B1007-1006

M10

6

12

9

20

6.4

12.6

64

295

375

35

3500

SS-B1007-1206

M12

6

18

12

25

6.4

12.6

64

340

445

54

5100

SS-B1007-1208

M12

8

18

12

25

8.4

16

80

360

465

60

5100

SS-B1007-1608

M16

8

20

16

29

8.4

16

80

435

565

108

8000

SS-B1007-1610

M16

10

20

16

29

10.5

18

90

445

575

111

8000

SS-B1007-2010

M20

10

24

19

30

10.5

18

90

490

640

172

13000

SS-B1007-2012

M20

12

24

19

30

12.6

20

105

505

655

180

13000

SS-B1007-2214

M22

14

26

22

35

14.7

25

140

625

805

452

17000

SS-B1007-2416

M24

16

29

25

40

16.9

28

160

730

960

662

20000

SS-B1007-2719

M27

19

34

28

46

20

34.5

200

835

1070

751

25500

SS-B1007-3022

M30

22

40

32

54

23.2

40.5

230

930

1190

948

31000

SS-B1007-3626

M36

26

44

36

62

27.5

46

280

1045

1315

1366

43000
